Technical Specifications

  • Maximum Inspection Size:500*400mm( Horizontal side * Vertical side)
  • Minimum Inspection Size:100*100mm( Horizontal side * Vertical side)
  • Paper Thickness:180-350g/㎡
  • Maximum Inspection Speed:180m/min
  • Imaging precision:0.11*0.1mm (accept customization in case of special requirement)
  • Size of mechanical appearance:6630x2820x1950mm (length, width and height)
  • Front side of camera:1-3 high-speed cameras
  • Conventional printing defect detection states:4k resolution ratio,36K horizontal frequency 3CCD German color high-speed camera
  • Laminating concave-convex detection states:8k resolution ratio, 36K horizontal frequency TDICCD panchromatic high-speed camera
  • Silk screen gloss oil detection states:8k resolution ratio, 36K horizontal frequency TDI CCD panchromatic high-speed camera
  • The reverse side:1 high-speed CCD camera (optional)
  • Software module(optional):color separation module
  • Feeder Type:Two Top Suction Feeder /One Top Suction Feeder + One Friction Feeder
  • Transmission mode:Fully Suction Platform

Equipment Characteristics

  • Scratch Proof:adopt top suction feeding method,compteley avoids scratch between knife and paper
  • Quickly switch:Feeder unit with top suction method is very easy to adjustment,Transportation no need adjustment due to adopt full suction method
  • 2 minutes can finish machine adjustment for new product
  • Aiming at the easily scratched products such as cosmetics,electronic and Metpet products with PVC materials,polished and varnished
  • Especially suitable for those frequently switched products and irregularly shaped products

Application industry

Folding
cartons
